PNR070CC15C401

Loading

PNR070CC15C401

Compound

Calcium carbonate compound:

It is some type of polypropylene compound which are used because of its good impact strength in applications exposed to impacts and cold air. It has also high process features and proper harness and impact strength. This makes this product suitable for various automotive parts such as battery, dashboard and home appliances. It is mainly used in textile. Its suitable distribution in matrix leads to low tensile strength and therefore low prices of final products.

Application:

  • Textile industries
  • Production of automotive parts
  • Home appliances

 Technical specifications of the product are as follows:

Properties Value Dimension Test Method
Physical
Melt Flow Rate (230 °C, 2.16 kg) 6 gr/10min ASTM D1238
Density 0.99 gr/cm^3 ASTM D 792
Shore D Hardness 68 - ISO 868
Mechanical
Tensile Strength @Yield 31 MPa ISO 527
Tensile Elongation @Break 55 % ISO 527
Izod Impact Strength (Notched) at 23 °C 4 KJ/m^2 ISO 180
Charpy Impact Strength (Notched) at 23 °C 4.5 KJ/m^2 ISO 179
Thermal
H.D.T (1.8 MPa) 58 °C ISO 75
Vicat softening point (50 N) 92 °C ISO 306
